APP and MPP Capacitor manufacturers in Pune
PQI Electrical & Automation is leading APP/MPP Capacitor Manufacturers in Pune, Suppliers, Dealers and Services in Pune .Our APP (All Polypropylene) and MPP (Metallized Polypropylene) Capacitors are of high quality and guarantee quality power factor correction and manageable power reactively. We provide capacitors which integrate durability, low losses and stable operation to fulfill the requirements of contemporary electrical systems.
About APP/MPP Capacitor
The APP (All Polypropylene) and MPP (Metallized Polypropylene) Capacitors are high-performance capacitors. The APP and MPP capacitors are utilized in electrical systems as reactive power and power factor Capacitors, as well as harmonic control to achieve reliable and efficient operation.
Types of APP/MPP Capacitor
As leading APP/MPP Capacitor Manufacturers in Pune, offering the following Types:
- Metallized Polypropylene Capacitors:
- Standard Duty: In the case of normal, stable industrial conditions (e.g., motor run, light duty PFC).
- Heavy Duty: It is more temperature and harmonic-demanding (e.g., industrial, non-detuned systems).
- Super Heavy Duty:
- Box Type/Oil Filled: This is applied in industrial applications of heavy workload and high stability.
- Internal Fuse/ Non-Self-Healing: In many cases internal fuse is used to ensure safety and greater resistance to surges of voltage.
Technical Specification of APP/MPP Capacitor
As well-known APP/MPP Capacitor in Pune, we provide Specifications such as:
| Rated Voltage | 400 V – 1000 V AC (depending on design) | Maximum AC voltage the capacitor can safely operate at. |
| Rated Capacitance | 1 µF – 100 µF | Capacitance value, indicating the energy storage capacity. |
| Tolerance | ±5%, ±10% | Acceptable deviation from rated capacitance. |
| Frequency | 50 Hz / 60 Hz | Operating frequency for AC applications. |
| Dielectric Type | Metallized Polypropylene (MPP) / Anti-Parallel Polyester (APP) | Ensures high stability, low losses, and long life. |
| Capacitance Stability | ±2% at 20°C | Minimal variation of capacitance with temperature. |
| Loss Tangent (tan δ) | ≤ 0.002 (MPP) / ≤ 0.005 (APP) | Indicates energy loss during AC operation; lower is better. |
| Insulation Resistance | > 50,000 MΩ at 500 V DC | Ensures minimal leakage current. |
| Temperature Range | -40°C to +85°C / +105°C | Safe operating temperature range for capacitor. |
| Overload Capability | 1.3 × Un for 2s | Can withstand temporary voltage surges without damage. |
| Self-Healing | Yes | Metallized film capacitors can recover from small dielectric breakdowns automatically. |
| Lifetime | 50,000 – 100,000 hours at rated voltage and 40°C | Expected operational life. |
| Safety Standards | IEC 60831-1, IEC 60831-2, IS 2834 | Compliance with international and national safety standards. |
| Mounting Type | Screw Terminal / Plug-in / Box Type | Flexible installation options for industrial applications. |
Features of APP/MPP Capacitor
We are APP/MPP Capacitor Suppliers in Pune, offering all upgraded multiple features such as:
- Long Service Life: APP Capacitor is the most thermally stable and durable capacitor that has a long working life.
- Self-Healing Property (MPP): The metallized polypropylene film in our MPP capacitors is self-healing in the event of minor internal faults and improves the reliability.
- High Insulation Resistance: APP Power Capacitors have great insulation resistance so that they can offer stable performance and reduce leakage currents.
- Compact & Lightweight Design: The APP and MPP capacitors are compact in size and can easily fit in ApFC panels and other reactive power systems.
- Maintenance-Free Operation: MPP Film Capacitor are developed to work for long without any troubles and with very low maintenance levels.
Applications of APP/MPP Capacitor
As APP/MPP Capacitor Dealers in Pune, our all types are used in various types of industrial sectors such as:
- Data Centers & IT Facilities: Our capacitors are compatible with APFC and harmonic filtering systems in data centers, which provide a stable supply of servers, UPS systems, and sensitive electronic equipment.
- Hospitals and Health Care Centers: We provide capacitors to ensure a reliable power supply for important medical machines, imaging, and life support systems that are clean.
- Renewable Energy Systems: Our capacitors can be used in solar conversion systems, wind turbines and in hybrid energy systems to handle reactive power and enhance the efficiency of the systems.
- Harmonic Filtering Systems: Harmonic filters capacitors are supplied by us to minimize distortions caused by non-linear loads like VFDs, UPS and welding machines.
- Power distribution networks: Our capacitors increase the stability of voltages, decrease reactive losses of power and make substations and distribution systems more efficient.
Why choose us?
As Providers of high-quality APP/MPP Capacitor Services in Pune Here’s why we stand out:
- Differentiated Capacitor Solutions: We supply capacitors of different voltage ratings, capacities, and configurations to suit the needs of industrial and other commercial applications.
- Increase in Energy Efficiency: We have APP/MPP capacitors that minimize reactive power losses, enhance power factor and reduce electricity costs.
- Improved equipment security: Our stable and clean power ensures the APFC panel, harmonic filter, and sensitive equipment are not affected by the voltage and harmonics.
PQI Electrical & Automation is well known APP/MPP Capacitor Manufacturers in Pune, Suppliers, Dealers and Services in Pune. Our high-performance APP (All Polypropylene) and MPP (Metallized Polypropylene) Capacitors offer high performance, efficiency and durability. APFC panels, harmonic filters and reactive power compensation systems. Our capacitors are very useful in the industry and commercial facilities to improve power factor, limit energy loss, and provide steady voltage.
FAQ's
Yes, our capacitors save power by minimizing losses in reactive power and enhancing power factor and reducing the cost and use of electricity.
Yes, they provide constant voltage and minimize harmonic stress, and safeguard APFC panels, harmonic filters, and sensitive electrical equipment.
Yes, we have long-term, trouble-free capacity of our capacitors and little maintenance.
